ATE MK20
- Product Code: P115
- Availability: In Stock
Can be remanufactured
BMW
| Error code | Description | |
| 71 | Pump motor / engine relay faulty | |
| 113 | Pump motor / engine relay faulty |
FIAT
| Error code | Description | |
| 701 | Pump motor faulty (with hydraulic aggregate) |
JAGUAR
| Error code | Description | |
| C1095 | Motor relay faulty |
RENAULT
| Error code | Description | |
| DF096 | Control unit malfunction |
VOLVO
| Error code | Description | |
| 112 | Pump motor | |
| 443 | Pump motor | |
| BCM-0050 | Control unit signal incorrect / no communication with BCM | |
| BCM-0070 | Pump motor supply voltage | |
| BCM-0072 | Pump motor mechanical failure | |
| BCM-0116 | No communication with AYC sensor | |
| BCM-0139 | Pre-pressure valve, brake-pressure booster | |
| BCM-C00201C | Pump motor | |
| ECM-940-F | Brake pressure sensor error | |
| P0070 | Pump motor relay incorrect |
Remanufacture may be possible
VAG (AUDI / SEAT / ŠKODA / VOLKSWAGEN)
| Error code | Description | |
| 01130 | Unacceptable permanent signal | |
| 01276 (04FC) | ABS hydraulic pump | |
| 16352 | Control module fault |
One of the bolt-down fuses fitted to various Volkswagen models sometimes fails. When this happens, the ABS unit no longer receives power. Check this fuse first and replace if necessary. Should the fuse blow again after this or should the ABS unit continue to generate error messages, an overhaul will still be required.
Cannot be remanufactured
ATE Teves MK20 IE ESP (Mercedes Benz): this is a non-standard type which we unfortunately cannot remanufacture.
- Multiple failures on wheel sensors
- No communication with ABS possible
- Malfunction on pump motors
Repair an ATE MK20?
The ATE MK20 can be found in various vehicles ranged in the mid and large segment from car manufacturers like: Audi, Ford, Renault & Volkswagen. The ABS unit consists of three components: the ECU (Electronic Control Unit), the HCU (Hydraulic Control Unit) and the pump motor. The entire ABS unit can be remanufactured. ACtronics has a revision solution available for the ATE MK20 for OEM (Original Equipment Manufacturer) numbers that can be selected in the drop-down menus on our website.
Possible defects and fault codes
The defects that occur in the MK20 can be related to several problems: the wheel sensors, the pump motor or the inability to communicate with the ABS unit. The defects can be noticed while driving as the ABS system can cause vibrations in the brake pedal. Fault codes can be read by the garage and when measuring live data while driving. It is important to make a good diagnosis before a unit is sent in so our engineers will know what problem to look for and apply the proper remanufacture solution.
ATE MK20 error codes
Fiat
- 701 - Pump motor faulty within the hydraulic aggregate
Jaguar
- C1095 - Motor relay
Renault
- DF096 - Control unit malfunctiony
VW Transporter
- 01130 - Unacceptable permanent signal
- 01276 - Hydraulic pump ABS incorrectly intermittent
- 16352 - Control module incorrectly intermittent
VW
- 1276 - Motor relay / Hydraulic pump
- 04FC - Motor relay / Hydraulic pump
